 Spray Sensor

Spray Pressure Sensor

The spray sensor is a sensitive, waterproof capacitive tactile sensor array designed to capture instantaneous and actionable spray pattern and spray pressure data generated by sprayed fluids or gases.

The Spray Pressure System captures distribution and impact pressure. The Spray Pressure System accurately identifies the location where sprayed fluid or gases land, by comparing electrical properties of the air surface to that of the spray. This technology is optimal for use in situations where spray pressures are infinitesimally small.

Features:

  • Live data output for on-the-spot analysis and refinement

  • Detect spray pressures of fine mists, pressure jets, and everything in between with accurate pressure measurement from 3 psi - 20 psi

  • Detect spray patterns even in situations where the spray has no measurable pressure with our proprietary sensing capabilities that compare the electrical properties of the air surface and spray

  • High sampling speed matches or exceeds the speed at which the discrete spray particles impact the surface, ensuring accurate capture of the full spray experience

  • Waterproof (IPX4 Rated)

  • Comes standard with our advanced but intuitive Chameleon Visualization Software.

GET PRICING
Spray Pressure Sensor


Spray Pattern Sensor

The Spray Pattern Measurement System is a first-of-its-kind large, high-speed sensor mat designed to visualize and characterize accumulated fluid deposition information for spray processes and is able to identify where a sprayed fluid or gas actually land.

The Spray Pattern Measurement System was designed for manufacturing, process engineers and researchers who are working with spray and/or coating processes involving very fine mists and who need to understand specific spray patterns as part of a manufacturing or coating process to control the quality of the finished product.

Many spray process requirements are met only through “trial and error”, meaning numerous adjustments to achieve a desired result.  PPS’s Spray Pattern Measurement System addresses this problem by digitizing, visualizing, and quantifying fluid deposition patterns that enable real-time feedback and electronic records for comparison and analysis, providing new levels of insight into spray and coating processes.

Features:

  • High resolution array sensor images the amount of fluid deposited over an area and provides instantaneous feedback for quick adjustments or analysis.

  • Ability to measure fluid deposition even for applications in which pressure is infinitesimal.

  • Waterproofed Sensor Mat capable of providing valuable data under any spray process conditions. This data shortens development time and helps improve the quality and cost of products and processes.

  • High performance capacitive sensing technology saves time and improves results by significantly reducing recalibration and repeated tests allowing developers to resolve problems and answer questions faster.

  • High speed USB 2.0 interface provides latency-free results.

  • Chameleon Visualization Software provides intuitive, easy to use, high-quality visualization and easy access to data for analysis and export to other applications.

GET PRICING
Spray Pattern Sensor

Applications

  • Semiconductor: Ensure spray tools used to clean materials have uniform pressure distribution to reduce contamination and damage

  • Testing: Test force of pepper spray to ensure doesn’t cause impact injury

  • Automotive: Measure impact pressure of water on vehicle underbodies in driving over puddles

  • Cosmetics: Measure and refine spray distribution of a perfume atomizer




Automotive

Application

  • Impact pressure testing of water sprayed when cars drive over puddles

Customer:

  • Multinational automotive manufacturer

Challenge:

  • Past solution used several single elements sensors placed in various locations and on engine components making it difficult to determine the peak water pressure

  • The sensors height (20mm) was disruptive to the water flow.

Solution:

  • PPS Spray Pressure Sensor System

Benefits:

  • Informs designers and engineers on the optimum location of water sensitive parts such as the radiator, suspension and exhaust tubes for successful long-term operation

  • High resolution array where thousands of points could be measured

  • PPS’ Spray Pressure Sensor was extremely thin and did not interfere with the experiment.



CONSUMER PRODUCTS


Application

  • Capture moisture spray patterns for consumer hand sprayers

Customer:

  • One of the largest consumer goods companies in the world

Challenge:

  • Moisture pressures are so low that it is difficult to measure.

  • In some situations, there simply isn’t enough pressure to measure, even when using a highly sensitive membrane-type sensor.

Solution:

  • PPS Spray Pattern Sensor

Benefits:

  • Enables the assessment of spray distribution for the light mist emitted by hand sprayers.

  • Quantify how much fluid is deposited on the sensor and in what pattern.

  • Designers can quickly and efficiently improve product designs to achieve optimal results



Semiconductor

semiconductor-spray-sensor-tactile

Application:

  • Silicon Wafer Cleaning System

Customer:

  • One of the largest Semiconductor companies in the world

Challenge:

  • Harsh industrial manufacturing conditions

  • Very low pressures

  • High resolution sensor required

Benefits:

  • The Spray Pressure Sensor Ensures uniform pressure distribution resulting in contamination reduction.

  • Optimizing the pressure distribution reduces damage to nano-structures on the silicon wafers.


Spray Sensor Presentation - Sensors Expo Conference 2018
